Features:
- 7 inch Touch screen, users can easily create and edit running programs.
- Heating function in Lysis and elution.
- Rapid extraction: 30~60min/time.
- Can process 32 samples per time
- 120 groups of programs can be stored.
- Automatic control system, no need connect to computer.
- Free programming to meet the needs of different reagent.
- High purity and excellent yield of nucleic acid.
- UV disinfection function, time range 1min~120min.
- Vibration mixing, adjustable in 3 gear: slow, middle and fast.
- Safety door design: When open the door, the program is automatically suspended. When close the door, the program can continue to run.
Parameters:
| Model | NP9032 |
| Sample volume | 20ul~1000ul |
| Sample throughput | 1~32 |
| Magnetic bead recovery rate | >95% |
| Plate types | 96 Deep-well plate |
| Difference between extraction holes | CV<5% |
| Lysis temperature | RT.+5°C~120°C |
| Elution temperature | RT.+5°C~120°C |
| Heating time | ≤4min(from room temperature to 120°C) |
| Temperature accuracy | ±1°C |
| Operation interface | 7-inch touch screen, 3 shortcut buttons |
| Extension interface | USB, RS232 |
| Program storage capacity | 120 |
| Lighting system | Yes |
| Disinfection function | UV light |
| Exhaust way | By fan |
| Data storage | Available, with built-in SD card |
| Power | 350W |
| Input voltage | AC85~265V/50-60Hz |
| Fuse | 250V 3A Ф5×20 |
| Dimension(mm) | 421x377x506 |
| Weight(kg) | 24 |
